Clamping lever | SM 1190

SCHOLZ MECHANIK GmbH

Colour	Diameter 1	Length 1	Length 2	Product number	Unit price	Buy

Product information "Clamping lever | SM 1190"

adjustable hand lever
with releasing button and
with threaded stud

Material:
threaded stud: steel, zinc plated, blue passivated
handle: plastic
Technopolymer (Polyamide PA)
glass fibre reinforced
temperature resistant up to 120° C
releasing button: plastic, black

Color / surface:
SW = black, matt RAL 9005

Lever adjustment by pulling or pushing.
The screw insert is detachably connected to the handle by a serration.
Lifting the handle releases the serration and the clamping lever can be swung into the most favorable clamping position.
When “released”, the handle engages again automatically.
The disengagement button enables effortless disengagement.
Application with limited clamping range or for certain clamping positions or if it is not necessary to remove the lever when screwing in.

RoHS-compliant: yes

Colour:	black
Compliance:	RoHS compliant
Material:	Bushing/Screw: Steel, Handle: plastic, Plastic, Thermoplastic
Speciality:	Locking by self-locking, With releasing knob, With threaded stud
Surface:	Steel - zinc plated
Type of use:	Clamping lever, Lever
