Indexing plunger / Stop bolt | SM 1273-4

from €8.79*

€9.12*

Prices incl. VAT plus shipping costs

Delivery time: 1-3 days working days

Delivery time: See variant in the table
This product is available in 8 versions.
Show all variants
Diameter 1
Length 2
Material
Product number: 37711

Description Datasheet
Filter
Product information "Indexing plunger / Stop bolt | SM 1273-4 "

Indexing plunger, screwable
Stop bolt, without locking device

Material:
zinc die casting,
zinc plated, blue passivated
ST: plunger: steel hardened
single components: steel
NI: plunger: stainless steel 1.4305
chemically nickel plated
single components: stainless steel
knob: black plastic
matt finish
not removable

RoHS-compliant: yes

Compliance: RoHS compliant
Material: Bolt: Stainless steel, Bolt: steel, Knob / Handle: Plastic, Stainless steel, Steel, Thermoplastic, Zinc die casting
Speciality: With knurling, Without detent lock, screwable, with knob / handle
Surface: Zinc die casting - galvanized
Type of use: Bolt, Indexing plunger / indexing pin
