Locating bolt, ribbed

Variants table
Diameter	Hight	Product number	Unit price	Buy

Product information "Locating bolt, ribbed | SM 1149"

with ribbed contact surface
with internal thread

Material:
free cutting steel,
case-hardened, blackened

RoHS-compliant: yes

Support pins with a ribbed support surface are used as supports,
stops and pressure pieces in general machine and equipment construction,
especially for workpieces with rough surfaces.

Compliance:	RoHS compliant
Element type:	Support bolt, bolts
Material:	Steel
Speciality:	Support surface ribbed
Surface:	Steel - burnished
