Locating bushing | SM 1273-68

Compliance:	RoHS compliant
Material:	Stainless steel
Speciality:	Fine thread, Standard thread, with external hexagon
Surface:	Stainless steel - bright
Type of use:	Ball support bolt / ball clamping bolt, Bushings

Zubehör

Lifting pin | SM 1273-83

self-locking with Shackle Material:pressure bolt: aluminium, red anodisedspring: stainless steelST:pin: heat-treated steel, tempered, manganese phosphatedshackle: heat-treated steel, tempered, manganese phosphatedNI: pin: stainless steel 1.4542, precipitation-hardenedshackle: stainless steel 1.4571 Pressing = unlockingResistant lifting element for quick and easy use, with moveable shackle. Special lifting devices, for example threads, are no longer required on the workpiece.Assembly: Press the button and hold it down | Insert the ball bearing pin | Release the button (the button must return to its original position). The button (A) is locked when it springs back to its original position due to the spring force. Do not operate the button under load!Disassembly: Press the button and hold it down | Pull out the ball bearing pin | Release the button.Notes:- Ball bearing bolts are designed for lifting and holding individual loads (not people!!). - Ball bearing bolts are not suitable for continuous rotation of the load. - Contamination (e.g. grinding sludge, oil and emulsion deposits, dust, etc.) can impair the function of ball bearing pins. - Before each use, ball bearing pins must be inspected for visible defects (e.g. deformations, breaks, cracks, damage, missing balls, corrosion, function of the release mechanism). - The balls must lock automatically by means of spring force. - Full mobility of the shackle must be ensured. - Damaged ball pins must not be used any further. - The load values F1 / F2 / F3 (table in data sheet) apply to lifting in a steel mount and x min. = 1.5 mm.Simple H11 boreholes are sufficient.The advantages of this lifting pin is corrosion resistants. The temperature range is up to +250 °C. RoHS-compliant: yesContains lead – Compliant with exemptions 6a / 6b / 6c.

From €82.92* incl. VAT

Details

Ähnliche Artikel

Locating bushing | SM 1273-66

Diameter 1: 16,00 | Form: A

with flangefor ball lock pins and socket pins Material:stainless steel 1.4305 Form A: with oval flangeForm B: with round flange Well suited for use with thin-walled components, e.g. in vehicle construction or aviation. The contact surface of the flange ensures optimum force distribution for components with low wall thicknesses.All versions are corrosion-resistant and wear-resistant. RoHS-compliant: yes

Variants from €16.39* incl. VAT

€29.14* incl. VAT

Details

Locating bushing | SM 1273-67

plain for lifting pins Material:stainless steel 1.4542 precipitation-hardened RoHS-compliant: yes Fast and secure mounting for the SM 1273-83 lifting pin.Used when a flat surface is required when screwed in, or for thin-walled parts and blind holes.A face spanner (SM 1273-67 ST) is required for installation.

From €40.89* incl. VAT

Details

Locating bushing | SM 1273-69

Diameter 1: 25,00 | Form: A

with collar for ball lock pins and socket pins Material:stainless steel 1.4305 Form A: with outer hexagonForm B: internal hexagonForm C: plain, with front hole optimized centering due to precise collar Easy installation, precise collar allows for good centering.Can be installed in various substrate materials,can also be used with thin-walled components,can be used on both sides.Form C with face hole is suitable for applications that require a flat surface when screwed in.All versions are corrosion-resistant and wear-resistant. Assembly: Form C with face hole can be installed with a cranked face pin wrench (SM 1273-67 STV 2) or with a face pin socket wrench (SM 1273-67 STS 4 or SM 1273-67 STS 5). RoHS-compliant: yes

Variants from €16.24* incl. VAT

€73.59* incl. VAT

Details

Locating bushing | SM 1273-68

with hexagonal collarfor lifting pins

with hexagonal collar
for lifting pins
