Socket pin | SM 1273-85
from €14.43*
€14.43*
Available in 5 days
Delivery time: See variant in the table
This product is available in 20 versions.
Product information "Socket pin | SM 1273-85 "
Socket pin
with spring-loaded balls
Material:
pin: stainless steel 1.4305
spring: stainless steel
handle: plastic (PA 6)
For a quick and easy locating and securing of axes and bolts.
The advantages of these socket pins are
corrosion resistants,
ergonomic grip,
can easily be fitted with the safety cord SM 1273-86 or with the ball chains SM 1273-87.
The temperature range is from -30 °C up to +80 °C.
Security Note:
Balls are spring-loaded and not locked as in article groups SM 1273-82, SM 1273-83 and SM 1273-84.
RoHS-compliant: yes
| Colour: | Knob / Handle: grey |
|---|---|
| Compliance: | RoHS compliant |
| Material: | Bolt: Stainless steel, Knob / Handle: Plastic, Stainless steel, Thermoplastic |
| Speciality: | with spring loaded balls |
| Type of use: | Bolt, Plug-in bolt / ball lock pin |
